Continuous product development has resulted in the introduction of the ClimaRad Ventura. This ventilation unit with heat recovery offers everything required to provide rooms with a healthy and comfortable indoor climate. The device is guaranteed to be applicable thanks to multiple connection options to the facade and is highly suitable for facades exposed to noise.
The ClimaRad Ventura V1C-S functions in the same way as the ClimaRad Ventura V1C, only this unit is centrally controlled on the water side.
Benefits ClimaRad Ventura V1C-S
- 100% applicability thanks to connection options, no parapet required;
- Possibility of heating and cooling at high speed;
- Suitable for facades exposed to noise;
- Draught-free ventilation guaranteed in high-rise buildings.
The ventilation unit supplies clean air from outside via a duct in the facade. The heat exchanger ensures the filtered outdoor air is preheated when it is blown into the room. Polluted indoor air is filtered and exhausted via the second duct in the outer facade. The reuse of heat by the exchanger provides the user with significant energy savings.
This ventilation unit with heat recovery is equipped with sensors for CO2, humidity, indoor and outdoor temperature and pressure sensors for balance control. They measure the air quality and automatically determine the required ventilation for each room.
The Ventura V1C-S is equipped with multiple convectors, so it cannot only ventilate rooms, but also heat and cool each room. The Ventura V1C was developed for the utility market, since the healthcare and business sector show an increasing demand for active cooling and LT heating. The main advantage is that the device can provide heating and cooling at high speed, compared to floor heating and cooling. The ClimaRad Ventura V1C-S is centrally controlled on the water side.
Also have a look at our other Ventura models: the ClimaRad Ventura V1X, Ventura V1D, Ventura V1C, Ventura V1C-C and Ventura V1C-V.
Summer night ventilation
The ClimaRad Ventura is equipped with the summer night ventilation function, which ventilates the room with cool outdoor air if the outdoor temperature is at least 2 degrees lower than the temperature in the room. If ‘cooling’ using outdoor air is required during summer nights, this function is an ideal solution. This unit has a high ventilation rate, meaning the cool air will be supplied to the room at higher speeds.
Functionality ClimaRad Ventura V1C-S
The ClimaRad Ventura V1C-S provides direct ventilation via the facade. Clean outdoor air is supplied and polluted air is exhausted outdoors. The unit is equipped with a heat exchanger that preheats the ‘clean air’. It uses the heat of the exhausted ‘polluted air’ to do so.
Functions ClimaRad Ventura V1C-S
- Regulate indoor air quality
- Filtering outside air
- Heating
- Decentralised ventilation
- Summer night ventilation
- Heat recovery
- Cooling
